Best 12V ~ 24V rear view Exterior Waterproof camera for Trucks / Bus
$75.00
SKU
Warm Tips:
It is rear view camera(mirrored ) with parking lines
Features:
This rear view LED/Waterproof/Color camera can be connected with your in-car DVD player or rearview moniter.
Heavy Duty Night Vision Rear View Camera For Reversing
For Trucks/ Caravans/ Buses/ Lorry
12/24v supported
waterproof IR camera with wide view angle
Color COMS Camera
Pick-up device 1/3'' CMOS
TV system PAL(CCIR) NTSC(EIA)
Scanning system PAL:265lines,50field; NTSC:525lines,60fied
Lens 2.8mm(option)
Number of pixels 500(H)X582(V) 510(H)X492(V)
Horizontal Resolution 420TV lines
Scan frequency 50HZ 60HZ
Electronic Shutter 1/50-1/100(sec) 1/60-1/100,000(sec)
S/N Ratio 48db (AGC OFF)
Minimun llumination 0.8LUX/F1.2
BLC Open
White Balance Auto
Gain Control (AGC) Auto
Video Output 1.0Vp-p.75,BNC conntctor
Synchronous System Internal Synchronization
Operating Temperature -20C ~ +80C
Power Supply DC 12/24V
Focal Distance 30mm to infinte
With Parking Lines
Package include:
1 x Camera (12v/24v compatible) (Cable Length: 50+/-2cm)
1 year warranty
